Duplo DP-J450 - Loading Document in Automatic Document Feeder (ADF) (Optional)

16
● Loading Document in Automatic Document Feeder (ADF) (Optional)
Load documents that consist of a series of sheets to be printed in the ADF.
When one or more documents are loaded in the ADF, master making and printing are
automatically repeated until the document tray is empty.
IMPORTANT:
ADF mode is automatically selected when a document is loaded in the ADF.
The ADF then takes priority over the document glass plate in the master making process.
The document can be loaded in the “portrait” or landscape” position.
IMPORTANT:
y A4, B5, and A5-size documents can be loaded in the “portrait” or landscape” position.
y Use landscape position when enlarging or reducing from standard-size documents to
standard-size paper, such as A4 to A3.
y A3 and B4 documents can only be loaded in the landscape position.
y Shadow erasure function cannot be available with the ADF.
►How to Load Document
1. Align the “document guides” with the marks for the size
of document to be loaded in the ADF.
2. Place the “document” with printing face up in the
document tray. Master making starts with the top
document in the tray.
IMPORTANT:
Do not attempt to remove or add to the documents in
the document tray while master making and printing
are in progress.
●Portrait
(
Vertical
)
Placement ●Landsca
p
e
(
Lateral
)
Placement
Printing
face up
Document Tray
Document
Document size
Document Guides
