Chapter 2 Operations
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
Page 15
Page 9
Page 8
Page 1
Cover 2
Cover 1
Tower A Tower B
• When more than two towers are connected,
load the covers on the paper feed trays above
the topmost tray paper of the rst tower and
below the bottommost tray paper of the last
connected tower.
C. Inserting one cover with paper ejection set to right side
(When the cover 1 is set in the processing mode:)
The tray stacking the cover is dierent from paper ejection to the left side.
1
2
3
4
5
6
7
8
9
10
Page 1
Page 5
xxth set
First set
Cover
Cover
Tower A
Cover
xx: No. of sets specied
(Insertion interval of cover)
• When inserting a cover after every xx sets
(No. of sets specied) where each set has ve
pages, load the covers on the paper feed tray
above the topmost tray paper as shown in the
gure.
1
2
3
4
5
6
7
8
9
10 10
1
2
3
4
5
6
7
8
9
Page 15
Page 1
Page 8
Page 9
Cover
Tower A Tower B
• When more than two towers are connected,
load the covers on the paper feed tray above
the topmost tray paper of the rst tower.
