Duplo DSC-10/60i User Manual

5-1
Chapter 5 Appendix
Chapter 5 Appendix
1. Specifications
Model DSC-10/60
Type Floor type vertical collator
The number of trays to
be collated
10 trays/tower
Maximum number of
units connectable
6
Feeding system Belt suction feed system
Conveyance system Roller belt conveyance system
Maximum paper
loading volume
65 mm / 2.56 inches in height
Paper size • Minimum width: 105 mm / 4.1 inches, Maximum width: 350 mm / 13.8 inches *
1
• Minimum length: 148 mm / 5.8 inches, Maximum length: 610 mm / 24.0 inches
*
1
:When the length of a paper exceeds 508 mm / 20 inches.
• Minimum width: 200 mm / 7.87 inches, Maximum width: 230 mm / 9.06 inches
Paper weight • Fine quality paper: 52 to 157 g/m
2
(cover 52 to 300 g/m
2
)
• Art/coated paper: 79 to 157 g/m
2
(cover 79 to 300 g/m
2
)
Paper type • Sheet
• Single-folded (Below 80 g/m
2
/within 10 trays)
• Cross-folded (Below 80 g/m
2
/within 5 trays)
Processing speed Maximum 10000 sets/hour in A5 LEF direction
* However, the speed diers according to the downstream unit.
Feed error detection Double-feed (Automatic paper thickness detecting, switching between thin and thick,
OFF), mis-feed, paper jam
Other detection
functions
No paper, conveyance path paper jam, conveyance path door open/close
Error display Displayed on control panel
Door open/close, no paper, paper feed error, and conveyance error of each tower,
downstream unit error, no paper, double-feed, mis-feed, and paper jam of each tray
Dimensions Single tower
855 (W) x 830 (D) x 1972 (H) mm / 33.66 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 1 tower:
1,485 (W) x 830 (D) x 1972 (H) mm / 58.46 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 2-connected towers
2,335 (W) x 830 (D) x 1972 (H) mm / 91.93 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 3-connected towers
3,185 (W) x 830 (D) x 1972 (H) mm / 125.39 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 4-connected towers
4,035 (W) x 830 (D) x 1972 (H) mm / 158.86 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 5-connected towers
4,885 (W) x 830 (D) x 1972 (H) mm / 192.32 (W) x 32.68 (D) x 77.64 (H) inches
LUL-HM + 6-connected towers
5,735 (W) x 830 (D) x 1972 (H) mm / 225.79 (W) x 32.68 (D) x 77.64 (H) inches
