5-2
Chapter 5 Appendix
Airborne noise • Single tower with LUL-HM, left side ejection
Equivalent continuous A-weighted sound pressure level: 74.8 dB
Sound pressure level: 90.7 dB (including the peak)
• Measurement condition:
Using ne quality paper (81.4 g/m
2
), A4 LEF direction, feeding from all trays, process speed
4000 sets/h.
Horizontal position: 1 m / 39.4 inches from the control panel
Vertical position: 1.5 m / 59.01 inches from oor surface
Power supply AC 220 to 240 V 50/60 Hz (EU)
AC 120 V 60 Hz (North America)
Current consumption 5.3 A, 980 W (Excl. D-PORT CONVERTER 5.1 A, 930 W)(EU)(One tower)
8.4 A, 960 W (Excl. D-PORT CONVERTER 7.9 A, 910 W)(North America)(One tower)
Mass (Weight) 305.5 kg / 673.50 lb (One tower)
Specications and dimensions are subject to change without prior notice for improvements.
