1-4
Chapter1 Before Use
3. Names and Operation of Control Panel
[16] [15] [14] [13] [12] [11] [10]
[8]
[9]
[7]
[6]
[4]
[3][2][1]
[5]
No. Name Operation
[1] Paper lamp The lamp of the paper feed tray feeding paper lights up.
When a paper feed tray runs out of paper, the corresponding lamp of the paper
feed tray blinks and the machine stops.
[2] Double-feed lamp When paper of a paper feed tray is double-fed, the corresponding lamp lights
up.
[3] Mis-feed lamp When paper of a paper feed tray is mis-fed, the corresponding lamp lights up.
[4] Jam lamp When a paper feed tray jams, the corresponding lamp lights up.
Even when the machine is in the standby state if paper jams at the sensor, the
corresponding lamp lights up.
When paper jams during paper feed, remove the paper after the machine has
stopped. The lamp lit will start blinking.
To Next Page
