2-27
Chapter 2 Operations
12.
Using the LUL-HM
The LUL-HM is a device for feeding paper sets containing several sheets (below 10 sheets) by hand marry or
hand feed.
It can be used only when paper ejection is set to the left side.
12-1. Hand Marry
1
Perform “Hand Marry” by using the PC CONTROLLER.
For operation method of the PC CONTROLLER, refer to the operation manual of the PC CONTROLLER.
2
Pull the paper guide of the hand marry
in the direction of an arrow according
to the paper size.
3
Set the auxiliary plates according to the
paper size as shown in the gure.
4
Insert the sets (less than 10 sheets)
collated in advance into the hand marry
in accordance with the instruction by
the PC CONTROLLER.
To Next Page
