DURAG D-ISC 100 P 2 User Manual

10 | Channel setup menu 4
114
D-ISC 100 x xx2
● Sets the timer for the control cycle to the value specified un-
der "Control cycle interval", i.e. the next control cycle will only
start again after the entire interval duration has elapsed.
● Request is carried out immediately; no additional confirmation
prompt.
10.3.6 [Specific parameter]
Information on the specific parameters can be found in the relev-
ant sensor manual.
10.3.7 [Setup]
10.3.7.1 [Common]
Customer name:
[
Customer name]
Press the
key to change…
● This allows a user-specific name to be entered for the re-
spective sensor.
● This name is then displayed in the measured value / status
display behind the sensor name.
10.3.7.2 [S1.1...S1.4 graphic]
Settings can be adjusted here for the graphic displays (bar
graph/XY graph) for individual channels of the respective sensor,
if these are active (see 8 Display setup menu 2 [}85])
Press the
key to change…
Automatic scaling:
[
Auto scale]
● If enabled (on, 1), the start and end values for the scaling are
automatically calculated based on the measured values to be
displayed
● If disabled (off, 0), the following three values are used:
Scale start value:
[
Scale start value]
● Start value for bar graphs or the Y-axis of XY graphs.
Scale end value:
[
Scale end value]
● End value for bar graphs or the Y-axis of XY graphs.
10.3.8 [Information]
List of version numbers for the sensor (this data is read only and
cannot be changed):
The
symbol means:
the information in this line is read-only here!
● [
Device]
● [
Description]
●
[ Device description revision common]
●
[ Device description revision specific]
