5 | Basic operation of the D-ISC 100
66
D-ISC 100 x xx2
No. Meaning Applies to (for example)
25 up ● for input: change value (via the cursor) (increase)
● for a menu: call up the next higher menu
● in the menu list: change / scroll through the selection (menu bar)
● for the virtual keyboard: change the selection
21 Key
ESC key [}203]
● abort, back (without loading)
● for input: switch to the next higher menu
● for a menu: call up the previous menu
27 to the right ● for input: cursor position
● for a menu: call up the next menu
● for a display (e.g. measured value):call up the next display
● in a list view: Check box ON
● in the virtual keyboard: select character
23 Key
Screen key [}204]
● change-over between the various display options
● for input: call up the virtual keyboard
● for selection: filter ON/OFF
26 down ● for input: change value (via the cursor) (decrease)
● for a menu: call up the next lower menu (submenu)
● in the menu list: change / scroll through the selection (menu bar)
● for the virtual keyboard: change the selection
22 Key
Enter key [}203]
● for input: confirm the input or adopt the
selection
● for a menu: open the next lower menu
● from the Measurement display: call up the channel menu (short-cut
key)
● for the virtual keyboard:
move the selected character to the input
Table5.1: Function of the keys
5.2 D-ISC 100 display
The user interface is available in different languages.
In this manual, screenshots are generally shown in English.
Reference to the text in local language is provided by the
additional English description.
The key terms are shown in square brackets, and start with the
symbol.
Example: [ Measuring values] …
The menu number in the header bar can also be used for
clarification. The menu numbers and associated menu items are
identical in all languages.
Menu: 3.2.S1.6
