3 | Device and Function description
D-ISC 100 x xx2
23
3.3.6 D-ISC 100 R
D-ISC 100 R
3010 20 46
84
61
X147 4849
62
46 85
85
10
The display
20
Keyboard
30
LEDs
46
Device fastening
47
Top hat rail
48
Rails for
shield terminals
49
Shield terminals
61
Power supply unit
62
Top hat rail module
D‑ISC100CPU module
(3.3.2 CPU module [}19])
84
USB port
85
Cable tie holder
X1
Plug terminals for
device connection
(see Technical data
for operating voltage)
Table3.12: Parts designation D-ISC 100 R
