13 | Technical data
150
D-ISC 100 x xx2
D-ISC 100 module - Profibus DP
Baud rate 9.6 kBits/s,
19.2 kBits/s,
31.25 kBits/s,
45.45 kBits/s
93.75 kBits/s,
187.5 kBits/s,
500 kBits/s,
1.5 MBits/s,
3 MBits/s,
6 MBits/s,
12 MBit/s
Automatic Baud rate detection is supported
Data transport layer PROFIBUS FDL
Restrictions The DPV1 and DPV2 application layers are not supported
Table13.9: Technical data D-ISC 100 module - Profibus DP
13.5.6.1 D-ISC 100 module - Profibus DP communication
settings
The D−ISC 100 Profibus DP (A) module uses the Modbus RTU
protocol for internal communication. For flawless operation, use
the factory setting for the D-ISC 100 Modbus RTU slave module
communication parameters:
Modbus RTU communication setting (factory setting)
Modbus address 20 Stop bits 1
Baud rate 19200 Termination On
Parity None
Table13.10: Modbus RTU module factory setting communication parameters
