Allgemeintoleranzen
ISO 2768 -m
Werkstück-
kanten
DIN ISO 13715
Gewicht: 8.67 kg
D-ISC 100C
AB2-MADEX-WA
0
A3
D. Vorrath
Name
Ursprung:
Maßstab:
Revision
90018208.iam
90018208_2
1 : 2
Diese Zeichnung ist Eigentum der DURAG GmbH und
darf ohne ausdrückliche Genehmigung weder verviel-
fält
igt noch Dritten zugänglich gemacht werden
Blatt
1
Bearb.:
Gepr.:
Freig.:
Datum
11.04.2017
Auftr.-Nr.:
119,5
202
270
250
180
