DURKOPP ADLER 756 A

Multi-functional corner knife station
Service Instructions 755 A/756 A - 00.0 - 02/2019 175
5. Press the Base corner button.
6. Set the value to 0 and press OK to confirm.
Fig. 172: Adjusting the corner knives electrically (3)
7. Use the buttons and to align the corner knife supports.
 The corner knife supports must be flush to one another.
8. Use the buttons
, , and to align the corner knife
supports such that they are straight.
Offset corner knife at seam end left zero  p. 374
• only for configuration: multi-functional corner knife station
• 0° - 30°
Set corner knife correction seam end
• -99.9 mm - 99.9 mm
Offset corner knife at seam end right zero  p. 374
• only for configuration: multi-functional corner knife station
• 0° - 30°
Symbols Meaning
flush
flush
