Stacker

Service Instructions 755 A/756 A - 00.0 - 02/2019 247

Fig. 241: Assembling the throw-over stacker (5)

12. Connect the pneumatic lines (15) of the pedal with the pneumatic

lines (14) of the machine.

 The pneumatic lines of the throw-over stacker are connected to

the compressed air maintenance unit via magnet valve Y25.

(14) - Pneumatic lines (15) - Pneumatic lines

⑭

⑮
