Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 319

Setting middle knife correction seam begin./seam end

 The display switches to Set middle knife correction seam begin./

seam end:

Fig. 301: Setting middle knife correction seam begin./seam end

Information

The arrows in the left half of the display indicate the correction direction:

Seam beginning

Correction outward

Correction inward

Seam end

Correction inward

Correction outward
