320 Service Instructions 755 A/756 A - 00.0 - 02/2019

Corner knife (Straight pocket, 755 A only)

 The display switches to Corner knife (Straight pocket).

Fig. 302: Corner knife (Straight pocket)

To set the corner knife:

1. Press the desired button.

2. Enter the desired value using the numeric keypad.

3. Confirm with OK.

Symbols Meaning

Corner knife On/Off

Set corner knife correction seam begin.  p. 321

• -9.9 mm - 9.9 mm

Set corner knife correction seam end  p. 321

• -9.9 mm - 9.9 mm

Default Chapter3
