Programming

Service Instructions 755 A/756 A - 00.0 - 02/2019 359

To set the global parameters:

1. Press the desired button.

 The user interface for setting the desired item is displayed.

Set machine process speed

• slow

• middle

• fast

Set password protection  p. 362

Set counting direction of piece counter UP

Set counting direction of piece counter DOWN

Knitwear mode On/Off

• only in combination with needle transport The needle transport is set

via the sewing head parameters  p. 317

Symbol Description
