408 Service Instructions 755 A/756 A - 00.0 - 02/2019

Internal devices

 The display switches to Internal devices.

Fig. 373: Internal devices

The area State can display 3 different status messages:

• conn = connected

• nc = not connected

• err = error

Addr DevName Meaning

2 SewMot Sewing motor

3 PowStep Motor transport axis

4 StepMot Middle knife motor

5 StepMot Corner knife support

6 StepMot Needle transport

7 StepMot Transport clamp left

8 StepMot Transport clamp right
