D 4.7 23
D_4.7_01_GB.fm 23-34
Example:
Sequence of flashing: 2-2-3.
Diagnostics according to the error message list: Charging air pressure -> Faulty sen-
sor input (e.g. short circuit or broken cable)
t = 800ms
t = 400ms
PAUSE
t = 2000ms
t = 400ms
t = 400ms
t = 800ms
t = 800ms
t = 400ms t = 400ms t = 400ms t = 400ms t = 400ms
PAUSE
t = 2000ms
2x
2x
3x
?
