Dynapac F 161 W - Description of Assemblies and Functions

B 2
B_F161W_01_GB.fm 2-22 01- 01.07
2 Description of assemblies and functions
Item Designation
1
t
Auger
2
t
Screed
3
t
Operator’s platform
4
t
Storage space for toolboxes on the left/right sides
5 t Paving thickness indicator
6 t Operating panel (can be moved to either side)
7
o
Protective roof
8
o
Working lights
9
t
Material compartment (hopper)
10
t
Truck push rollers
11
t Tube for sensor rod (direction indicator) and holder for levelling shoe
12 t Front tandem shaft (with the F 161-8 W drive)
13
t
Shaft with front wheel drive (F 161-6 W)
14
t
Traction roller
15
t
Traction arm rail
16
t
Levelling cylinder for paving thickness
17 t Arm
18 t Rear wheels
19
o
Hydraulic hopper lid
20
o
Exhaust of asphalt vapours
t = Standard equipment
o = Optional equipment
F161W_2.wmf
1
3
13 11
5
17
6
2
9
10
121516
7
14
8
18
4
19
20
