5.2 Allowed angle of rise and slope
A
Before operating your machine in an inclined position (gradient, slope, lateral inclina-
tion) which is above the specified limit value, please, consult with the customer serv-
ice for your machine!
5.3 Allowed angle of driving up
5.4 Turning radius, turning circle
Internal turning radius 4,45 m
Turning circle 15,30 m
635_side_Dyn.bmp,F161W_side.tif
max 15°
max 15°
max 15°
F161W_side.tif
max 14°
max 14,4°
