5 Technical data, standard configuration

5.1 Dimensions (all dimensions in mm)

For the technical data of the screed, see the operating instructions of the screed.

F161W_side.tif/F161W_front.tif

6810*

2645

1900

1600

3100

1200

3600

2055

3400

2500

1340925

*VB510 T/TV
