D 3.2 14
D_3.2_01_GB.fm 14-18
Front wheel drive pressure regulating
valve (94) (o)
The drive pressure of the supplementary
front wheel drive can be adjusted here.
- Engage the front wheel drive with the switch.
- Pressure display: see pressure gauge (94a).
A
Adjust the pressure on the moving paver so that the driven front wheels do not spin.
Pressure gauge of the front wheel
drive (94a) (o)
It shows the drive pressure of the sup-
plementary front wheel drive.
Pressure adjustment with valve (94)
Experimental value: about 110 - 140 bar
Maximum value: about 200 bar)
A
In case of the engagement of the anti-
spin regulator (ASR - o) the optimum
value is automatically adjusted to the variable adhesion relations.
This requires the adjustment of about 200 bar maximum pressure.
F0105_A1.TIF
94
F0104_A1.EPS
94b
