5.7 Traction drive/chassis
5.8 Motor
5.9 Hydraulic system
Drive
Continuously variable hydrostatic drive, with
pump and engine
Transmission
Through two-stage transmission with differential
gear and differential lock
Speeds (see above)
Drive wheels
4 x 13.00 R-22.5 (air filled tyres) (water filled tyres
o)
Steering wheels 4 x 560 / 390 - 300 (elastic solid rubber tyres)
Front wheel drive F 161-6 W /
F161-8 W (o)
2 / 4 wheel hub hydro-motor, freely selected,
variable drive performance, Anti-spin control (o)
Brakes
Travel drive brake, 2 hydr. disc brakes
1 mech. parking brake
Make/type Deutz TCD 2013 L04 2V
Model 4-cylinder (water cooled) Diesel engine
Performance 116 KW / 158 HP (at 2100 rpm)
Volume of fuel tank (see chapter F)
Pressure build-up
Hydro-pumps driven by transmission gear
(directly connected to the engine)
Pressure distribution
Hydraulic circuits for:
- Machine drive
- Material conveying and distribution
- Screed drives for tamper / vibration (option)
- Cylinder actuators for steering, hopper,
levelling, screed lifting, extending/retracting
screed parts, auger lift (option)
Hydraulic oil reservoir - volume (see chapter F)
