5.6 Capacity data
*The maximum working width depends on the paving conditions!
Screed used
Basic width
(without cut-off shoes)
minimum paving width
(with cut-off shoe)
continuously hydraulically
adjustable up to
Maximum paving widths
(with attachments)
VB 510 T/TV (E) 2,55 2,00 5,10 8,10 m
VB 510 T/TV (E) Plus 2,55 2,00 5,10 * m
VB 600 T/TV (E) 3,00 2,45 6,00 * m
VB 600 T/TV (E) Plus 3,00 2,45 6,00 * m
Travelling speed 0 - 16,5 km/h
Working speed 0 - 26,7 m/min
Layer thickness 0 - 300 mm
Max. grain size 40 mm
Theoretical paving performance 650 t/h
