D 1.5 23
D_1.5_01_GB.fm 23-24
Front side
Item Designation Brief description
55
Emergency stop
button (o)
Its function and use are similar to those of the emergency
stop button on the operating panel (14).
It is important in such dangerous situations, which cannot be
observed by the driver.
56 Horn Its function is similar to the button (7) on the control panel.
57 Levelling cylinder
Its function and use are similar to the function of the switch
(30) on the control panel.
Switch (61) must be set „manual“ position.
58 Feeder (o)
Its function and use are similar to the function of the switch
(17) on the control panel.
The switch must be set to „auto“.
59 Auger
Its function and use are similar to the function of the switch
(25) on the control panel.
- The switch must be set to „auto“.
60
Screed extension/
retraction
With this the extendable parts of the Vario screeds can be
hydraulically extended or retracted.
61
Levelling automatic
system
manual: Height adjustment is possible with switch (57) (or
switch (30) on the operating platform)
auto: automatic height adjustment with grade signal
transmitter
62
Levelling „cross-
connection“ (o)
To control the levelling cylinder on the other side of the ma-
chine.
A
It overrides the „manual“ switch position.
