D 3.2 2
D_3.2_01_GB.fm 2-18
Battery main switch (72)
The main switch interrupting the circuit
between the battery and the main fuse is
located under the left maintenance flap.
m
Secure the open service lid with the out-
rigger rod.
A
For the assignment of all fuses, see
chapter F.
- For switching off, turn the key (72) to
the left and pull it out.
A
Do not lose the key as in this case the
paver finisher can no longer be moved!
Tankhood_LH.eps
72
F0077_A1.EPS/F0078_A1.EPS
72
