Dynapac F 161 W - Material Compartment (Hopper); Material Conveying; Material Distribution

B 16
B_F161W_01_GB.fm 16-22 01- 01.07
5.10 Material compartment (hopper)
5.11 Material conveying
5.12 Material distribution
Volume
about 5,7 m
3
= about 12,5 t
Minimum inlet height, center 475 mm
Minimum inlet height, outside 595 mm
Conveyors Left and right side separately controllable
Drive Hydrostatic, continuously controllable
Conveying volume controller Fully automatic via configurable switching points
Augers Left and right side separately controllable
Drive
Hydrostatic external drive, continuously
controllable independent from the conveyor
Auger halves can be switched to opposite
directions
Conveying volume controller Fully automatic via configurable switching points
Auger height adjustment
- mechanically via chain
- mechanically (option)
hydraulically (option)
Auger extension With extension parts (see auger extension chart)
