F 8.2 12
F_8.2_01_GB.fm 12-20
Fuses in terminal box (B)
F. A
5.1 Travel drive 5
5.2 Differential lock, ASC 10
5.3 Temperature control, electric heating 7.5
5.4 Gas heater 10
5.5 Integrated receptacles 10
5.6 Integrated receptacles 10
5.7 Integrated receptacles 10
5.8 Integrated receptacles 10
5.9 Engine start 10
41 Engine feedback control 25
50 Main fuse for auxiliary functions 30
51 Spraying system 3
52 Emulsion spraying system 3
53 Diesel tank filler pump 5
54 Rotary beacon 3
55 Lighting on glassfibre-reinforced roof 10
56 Asphalt fume control system or xenon light (o)3
59 Working lights (o)15
84 Seat heating 10
85 Windscreen wiper 7,5
86 Reserve 10
89 Travel drive (brake light) 2
F5.5
!
