5Towing
f
Heed all regulations and apply all safety measures applicable for towing heavy
construction machines.
m
The towing vehicle must be capable of securing the paver, even on slopes.
Use only approved tow bars!
If necessary, remove any attachments and accessories from the paver finisher and
the screed until the basic width has been attained.
Set the two-stage transmission using le-
ver (1) to position „0“.
- Attach the tow bar to the coupling (2)
located in the bumper.
- Slowly and carefully tow the paver fin-
isher from the construction site or the
hazardous area via the shortest route
A
Now carefully and slowly tow the paver
finisher out of the construction area.
m
Always only tow the shortest distance to
the means of transport or the next park-
ing possibility.
F0102.EPS
1
F161Wb.Tif
2
