F 11.3 3
F_11.3_01_GB.fm 3-8
1.2 Filling volumes
** Only on planer-finishers with wheel drive (direct drive)
*** Only on planer-finishers with wheel drive (manual gearbox)
Operating substance Volume
Fuel tank Diesel fuel 280 litres
Hydraulic oil reservoir Hydraulic oils 175 litres
Pump distribution gear Gear oil 90 4.5 litres
Planetary gear
Travel drive **
see the section
"Lubricants and operat-
ing substances"
2.8 litres
Drive axle (differential)*** Gear oil 90 18.0 litres
Conveyor gear transmission
(each side)
Gear oil 220 1.5 litres
Central lubrication system
(option)
Grease
Batteries Distilled water
