C 1.2 11
C_1.2_01_GB.fm 11-12
6 Safely parking the vehicle
m
When the equipment is parked at a loca-
tion accessible to the public, it must be
secured in such a way that unauthorized
persons or playing children cannot dam-
age the vehicle.
- Pull off the ignition key and the main
switch (1) and take it with you – do not
hide them somewhere on the ma-
chine.
m
Do not turn off main switch (1) until 15
seconds after the ignition has been turned off!
A
The engine electronics need this length of time to back up data.
- Protect the operating panel with the
dust cover (2) and lock it.
- Store loose parts and accessories in a
safe place.
A
Secure the dust cover (2) during opera-
tion with the lock on the terminal box un-
der the maintenance flap on the RH side!
F0077/0078_A1.EPS
1
Bedienpult_SPS_Kette_635_2.wmf/Vandalism.bmp
2
Dieseltank.eps/Vandalism.bmp
2
