Relays in operating panel
Relays
K
11 Idling speed
12 Conveyor/auger, left
13 Conveyor/auger, right
17 Screed function
32 Flasher sensor (lighting)
33 Engine stop
39 Start interlock
80 Timer relay, revers. conveyor, right
81 Timer relay, revers. conveyor, right
149.1 Priority circuit for extending/retracting screed, left
149.2 Priority circuit for extending/retracting screed, right
133 Function interlock (Italy)
