Dynapac F 161 W - Page 228

F 11.3 6
F_11.3_01_GB.fm 6-8
Auger type I
Auger type II
** for new installation
Operating substance Volume
Auger bevel gear (each side) Gear oil 90 0.6 litres
Operating substance Volume
Planetary gear
Augers (each side)
Gear oil 90 0.5 litres
Auger box Gear oil 460 2.5 litres
Outer auger bearing
(per bearing)**
Hot bearing grease 115 grammes
