D 1.5 7
D_1.5_01_GB.fm 7-24
Item Designation Brief description
12
Ignition switch and
lighting switch
Key inserted: Ignition on
Key pulled out: Ignition, engine off.
Key positions:
0 Lights switched off
1 Parking lights / rear lights, instrument panel light,
working floodlight as applicable
2 Driving lights
3 Headlights
A
Override the interlocking between 1 and 2 by depress-
ing them.
13
Query of fault / fail-
ure
If one of the control lights indicates the fault in the traction en-
gine, then a code can be queried from the machine, which
means a specific fault.
Keep pressing the button, until a three digit error code is dis-
played.
A
See Chapter „Operating Failures“ for querying the error
code.
14
Emergency stop
button
In case of danger (persons are exposed to risk, danger of col-
lision etc.), press it!
- Pressing the emergency stop button switches off the en-
gine, the drives and the steering system.
Steering away, lifting the screeds and other manoeuvres
are not possible in such cases! Risk of accident!
- The emergency stop button does not shut off the gas heat-
ing system.
Manually close the main shutoff valve and both cylinder
valves!
- In the case of electrical malfunctions, the engine must be
turned off manually at the leverage of the injection pump.
To restart the engine, the button must be pulled out again.
15 has no function
