Item Designation Brief description
43
Oil pressure indica-
tor for the hydraulic
traction drive (red)
It must go out soon after start-up. Consider the time of warm-
ing up. The hydraulic oil may be too cold and rigid.
m
If the light does not go dark, do not turn on the trac-
tion drive.
A
The lamp goes out at a pressure of 2.8 bar = 40 psi.
44
Oil pressure indica-
tor for the Diesel en-
gine (red)
It must go out soon after start-up.
m
If the lamp stays on, turn off the engine immediately.
See the further possible faults in the operating in-
structions for the engine
45
Control light
differential lock
It is on, when the differential lock is engaged.
A
Use the differential lock in case of poor grip (loose
soil). It can be engaged during travel.
m
Do not turn with engaged differential lock and lifted
screed. The differential lock may get damaged.
f
Do not use the differential lock for travel. Risk of acci-
dent due to limited steering ability!
46
Battery indicator light
(red).
It must go out after start-up at a higher speed.
- Stop the engine.
47
„Parking brake“ light
(red)
It is on when the parking brake is applied.
When the drive lever is moved and the parking brake is en-
gaged, the paver finisher cannot be started.
m
Before releasing the parking brake, set the drivel le-
ver again to central position.
48 has no function
49 Service hour meter
The service hours are counted by the machine with running
engine.
Daily maintenance of the paver finisher (see chapter F)
50 Fuel gauge
Continuously observe the fuel gauge.
m
The gas oil tank may never go empty! Otherwise, the
entire fuel system must be bled (vented).
51
Engine temperature
(o)
Green area: normal temperature.
m
In case the display is at or in the red range, stop the
paver, (set drive lever to neutral position), and let the
engine cool at idling speed. Find the cause and if nec-
essary eliminate it (see Chapter „Operating Faults“).
52 RPM meter (o)
The speed is displayed in revolutions per minute (rev/min).
A
The RPM can be modified with the speed regulator.
