MGR10 A/B/C - Revision : I (for 7.0 software revision) 32
If a low limit is higher than the high limit , an error message is displayed :
** INCORRECT **
Upper limit is smaller than Lower Limit
The operator must correct the value before escaping the menu .
The Green Pass front panel LED will light when the measured value is correct and within the set
limits, the Red Fail LED will light and the warning beeper will sound if the measured value is
higher than the Max limit set or lower than the Min limit set. The MGR10 screen will also display
PASS or FAILED with >> to show value to high and<< to show value to low.
Figure 4.5.1 Measurement screen with limits
O / C :
To select the open voltage limitation (standard NFC 93050) from the limits menu , press on [C/O]
Cancel the limitation mode by pressing on [Off]
Or select a 20 mV open voltage by pressing on [20 mV]
Or select a 50 mV open voltage by pressing on [50 mV]
Press on [OK] to go back to the previous page
Press on [Quit] to escape the menu
The open voltage limitation mode is indicated on the upper right corner of the LCD display.
AUTO1: 30m +10.0A (AVE) SLOW
+ 9.620 m
5.0000 m >> OK << 15.000 m
Meas Sing
To Next Page
