MGR10 A/B/C - Revision : I (for 7.0 software revision) 75
6.3.4 Other function Commands
Temperature Compensation Group
SENSe:TCOMpensate:STATe <ON|OFF> or <1|0>
Enables or disables the temperature compensation facility.
Temperature compensation is not available in FAST mode. Attempting to set the state “ON” will
generate an “execution error”.
SENSe:TCOMpensate:STATe?
Returns “0” (OFF) or “1” (ON).
SENSe:TCOMpensate:MODE <EXT> or <MAN,manual temperature>
Sets the temperature compensation facility to either external Pt100 probe measurement, or to a
fixed temperature, which is entered in the current temperature unit (ºC or ºF). Range is 0 - 100 ºC
(32 - 212°F)
.
SENSe:TCOMpensate:MODE?
Returns “EXT”, or “MAN”,<manual temperature>.
SENSe:TCOMpensate:COEFficient <CU|AL>or <USER,user coefficient>
Sets the temperature coefficient to Copper, Aluminium or to a user-defined value, which is entered
in ppm/ºC (0 - 9999).
SENSe:TCOMpensate:COEFficient?
Returns “CU”,<fixed copper coefficient>, or “AL”,<fixed aluminium coefficient>, or
“USER”,<user coefficient>. The coefficients are quoted in ppm/ºC.
UNIT:TEMPerature: <C|CEL|F|FAR>
Sets the temperature unit to ºCelsius or ºFarenheit.
UNIT:TEMPerature?
Returns “CEL” or “FAR”.
SENSe:TCOMpensate:REFerence <temperature value>
Sets the reference temperature. This is the temperature to which resistance measurements are
compensated (normally 20ºC). It is entered in the current temperature unit (ºC or ºF). Range is 0 -
50ºC (32 - 122°F), in integer values of ºC, or the ºF equivalent.
SENSe:TCOMpensate:REFerence?
Returns the reference temperature in the current temperature unit.
