MGR10 A/B/C - Revision : I (for 7.0 software revision) 36
4.7 General setup menu
Press
to select the setup menu
RESET :
Press [RESET] to reset the measurement parameters with default values . This function is suitable
when the operator doesn’t know how to set the parameters to perform a measurement .
Confirm the reset by pressing [Yes]
Or escape the menu by pressing [No]
Mem :
Press [Mem] to reach the10 parameter memories control menu
Press [RCL] to recall an existing memory number
Enter the memory number between 0 and 9 with the numeric keypad , the parameters are
immediately loaded in the unit operating memory .
Press [STO] to save a parameter set in a memory location
Enter the memory number between 0 and 9 with the numeric keypad . If the memory location is
already occupied with parameters , the display will ask to confirm overwriting .
Press [Yes ] or [No]
Press [List] to get the memory list :
Mem 0 In use Mem 5 Free
Mem 1 In use Mem 6 Free
Mem 2 In use Mem 7 Free
Mem 3 In use Mem 8 Free
MENU
MENU
Set Rem Key
RESET Mem Lcd Up I/F Lock Quit >>
