MGR10 A/B/C - Revision : I (for 7.0 software revision) 37
Mem 4 Free Mem 9 Free
 Press [OK] to go back to the previous page
 Press [CLR] to clear a memory number
 Enter the memory number between 0 and 9 with the numeric keypad
 Confirm the reset by pressing [Yes]

Or escape the menu by pressing [No]
 Press [OK] to go back to the previous page
Lcd :
 Press on the key with a light bulb drawing to power on or off the LCD backlight
 Keep pressed on the key with a clear square to reduce the LCD contrast
 Keep pressed on the key with a dark square to increase the LCD contrast
 Press [OK] to go back to the previous page
Setup :
 Press on [Setup ] to reach the unit system setup ( audible signal , date , time , language ,
temperature unity , software revision ,…..)
 Press on [Beep] to set or rest an audible signal when pressing a key
 Press on [On] to set the audible signal
 Press on [Off] to reset the audible signal
 Press [OK] to go back to the previous page
 Press on [Time Date] to set the date and time
 Press [Chg] to set the time
 Enter the new time with the numeric keyboard according to the exact requested format
( 6 digits)
 Press [OK]to enter

Press [OK] to display the date
 Proceed as for the time to change the date ( date is Y2000 compatible )
 Press [OK] to go back to the previous page
 Press on [Lang] to select the language
 Press on [Eng] to select English language
 Or press on [Fra] to select French language
 Press [OK] to go back to the previous page
 Press on [Temp unit] to select the temperature unity : °C or °F
 Press on [°C] to display temperature in degree Celsius
 Press on [°F] to display temperature in degree Farenheit
 Press [OK] to go back to the previous page
 Press on [Line Freq ] to select the line frequency to insure a good measurement stability .
 Press on [50] for a 50Hz line frequency (Europe)
