Eaton MGR10 User Manual

MGR10 A/B/C - Revision : I (for 7.0 software revision) 10
1.5 MGR10B technical specifications
1.5.1 Measurement Accuracy
Range Max. Current Resolution Accuracy at full rated current Temp. Coefficient
30 k 100A 1
±(0.03%Rdg+0.02%FS)
50 ppm
3 k
1mA
100m
±(0.03%Rdg+0.01%FS)
50 ppm
300
10mA
10m
±(0.03%Rdg+0.01%FS)
50 ppm
30
100mA
1m
±(0.03%Rdg+0.01%FS)
50 ppm
3
100mA
100
±(0.05%Rdg+0.01%FS)
50 ppm
200m
100mA
10
±(0.05%Rdg+0.01%FS)
50 ppm
30m
Not available
3m
Not available
The accuracy is quoted at full rated current and the display count is 30,000 plus sign and unit.
FS = Full Scale
1.5.2 Programmable current
The measurement current is adjustable on each resistance range as follows:
Range Max Current Min Current Steps
30 k 100

A 10

A 1A
3 k
1mA
100

A 10A
300
10mA 1mA
100A
30
100mA 10mA 1mA
3
100mA 10mA 1mA
200m
100mA 10mA 1mA
30m
Not available
3m
Not available
The accuracy of current is ±0.1% .
Open circuit voltage is 5 V +/-5% . Can be limited to 20 or 50 mV to comply with NFC93050
1.5.3 Accuracy against current level
Range 100% Current 50% Current 10% Current
30 k
±(0.03%Rdg+0.02%FS) ±(0.04%Rdg+0.02%FS) ±(0.05Rdg+0.02%FS)
3 k
±(0.03%Rdg+0.01%FS) ±(0.04Rdg+0.01%FS) ±(0.05Rdg+0.01%FS)
300
±(0.03%Rdg+0.01%FS) ±(0.04Rdg+0.01%FS) ±(0.05Rdg+0.01%FS)
30
±(0.03%Rdg+0.01%FS) ±(0.04Rdg+0.01%FS) ±(0.05Rdg+0.01%FS)
3
±(0.05%Rdg+0.01%FS) ±(0.06Rdg+0.01%FS) ±(0.07Rdg+0.01%FS)
200m
±(0.05%Rdg+0.01%FS) ±(0.06Rdg+0.01%FS) ±(0.07Rdg+0.01%FS)
30m
Not available
3m
Not available
