Eaton MGR10 User Manual

MGR10 A/B/C - Revision : I (for 7.0 software revision) 31
4.5 Limits
Press on :
To select the Limits menu.
Two options are then available ,
[Meas] which enables limits to be set with reference to the
measured values or
[O/C] which enables the open circuit voltage to be limited to either 20mV or 50
mV( NFC93050 standard B , C conditions )
Meas :
 Press on [Meas] to call the measurement limits menu.
 Press on [Alm] to activate or not the audible alarm .
 Press on [On] to activate the audible signal when measurement result fails
 Or press on [Off] to cancel the audible alarm .
 Press on [OK] to go back to the previous page
 Press on [Max] to set the maximum value
 Press on [Chg] , lto change the value , then enter the new value in Ohm in using the
numeric keypad .
 Press on [OK] to enter the value.
 Press on [OK] to go back to the previous page
 Press on [Min] to set the minimum value and proceed the same way for the upper limit .
 Press on [On] to activate the comparison mode
 Press on [Off] to cancel the comparison mode.
 Press on [OK] to go back to the previous page
CLE
LIM.
LIMIT
Limits :
Meas O/C Quit
