MGR10 A/B/C - Revision : I (for 7.0 software revision) 50
6-1-5 Description of the input output signals
* COM_IN : electrical common between input signals.
* COM_OUT : electrical common between output signals.
* CTRLIN (input) : request for remote control of the measurement unit.
* MES_DCH (input) : selection of the measurement or discharge state :
Logical state HIGH : Measurement
Logical state LOW : Standby
* N0,N1,N2,N3 (input)
: binary coded data lines for the number of the parameters set :
N3 N2 N1 N0 Memory
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
. . . . .
1 0 0 1 9
* CTRLOUT (output) : acknowledgment of the CTRLIN signal.
* EOT (output) : the contact of the relay is closed at the end of the test.
* PASS (output) : the contact of the relay is closed when the test pass.
* FAIL HIGH(output) : the contact of the relay is closed when the test fail by values too high.
* FAIL LOW(output) : the contact of the relay is closed when the test fail by values too low .
* ERROR (output) : the contact of the relay is closed when an error occurs (connection error ,
resistor too high ,….)
