04/10 MN04020001Z-EN
Parameter menu (PAR)
101
P9.8 337 / PID controller, actual value limiting, maximum 100.0
0 Setting range: 0.0 - 100.0 %
P9.9 340 / PID controller, control deviation 0
0 Not inverted
1 Inverted
Inverted PID control (P9.9 = 1) is used in applications in which the
feedback value generator supplies an inverted signal.
Example: With increasing pressure, a pressure sensor’ output
signal (+10 V…0 V = 0…max. bar) drops.
P9.10 132 / PID controller, D rate time 0.00
Setting range: 0.00 - 10.00 s
Differential time constant
P9.11 1431 / PID controller, output filter, deceleration time 0.0
Setting range: 0.00 - 10.00 s
P9.12 1016 / Sleep mode, frequency 0.00
Setting range: 0.00 - 6.4 Hz
The frequency inverter stops automatically if the frequency of the
drive drops below the sleep level defined by this parameter for a
longer period than the time defined by parameter P9.14.
P9.13 1018 / Sleep mode, wake up frequency 25.0
Setting range: 0.00 - 100 %
The wake up frequency defines the value below which the actual
value must drop before the RUN mode of the frequency inverter is
restored.
P9.14 1017 / Sleep mode, deceleration time 30
Setting range: 0 - 3600 s
This parameter determines the minimum period in which the
frequency inverter must stay below the frequency set at P9.12
before the frequency inverter is stopped.
P9.15 1433 / Hysteresis, upper limit 0.0
Setting range: 0.00 -100 %
The FBV (Feedback Value Check) message P5.1 (2.3) = 25 is
output if the actual value in RUN mode is below the lower limit
value P9.16. It stays active until:
• The actual value exceeds the upper limit value P=9.15.
• The frequency inverter switches from RUN mode to STOP mode.
P9.16 1434 / Hysteresis, lower limit 0.0
Setting range: 0.00 - 100 %
See P9.15
P9.17 1435 / PID controller, max. controller deviation 3.0
Setting range: 0.00 - 100 %
If the PID controller is activated (P9.1 = 1), and the deviation
between the setpoint and the actual value exceeds the value
entered here, the PID monitoring is activated. Setting at P5.1
(2.3) = 12.
PNU ID Access right
RUN
Value Description Factory setting
(P1.3)
