Appendix
04/10 MN04020001Z-EN
176
List of parameters
The abbreviations used in the parameter lists have the following
meaning:
Quick configuration (basis)
The quick-start assistant can be switched off in the first parameter
(P1.1) by entering a zero (access to all parameters).
In parameter P1.2, you can switch to the specified application
setting with the quick-start assistant (see table 4, page 44).
The quick-start assistant ends this first cycle by automatically
switching to frequency display (M1.1 = 0.00 Hz).
By selecting the parameter level (PAR) again, besides the selected
parameters for the quick-configuration, the system parameters (S)
are also shown in other cycles.
PNU Parameter number
ID Identification number of the parameter
RUN Access rights to the parameters during operation
(RUN): / = Modification permissible,
- = Modification only possible in STOP
ro/rw Parameter read and write permissions via a fieldbus
connection (BUS)
ro = read only
rw = read and write
DS Factory setting of the parameters
User
setting
User setting of the parameters
h
When first switching on or after activating the default
settings (S4.2 = 1), you are guided step by step through
the provided parameters by the quick-start assistant. The
defined values are confirmed with the OK button or they
can be changed to suit your application and the motor
data.
PNU ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
P1.1 115
/
rw Parameter conceal 0 = All parameters
1 = Only quick configuration parameters
73 1
P1.2 540 - rw Drive Setup 0 = Basic
1 = Pump drive
2 = Fan drive
3 = Hoisting device (high load)
73 0
P1.3
1472 - rw Country specific default
settings (FS)
0 = EU
1 = USA
73 0
P6.1
125 / rw Control place 1 1 = Control signal terminals (I/O)
2 = Control unit (KEYPAD)
3 = Field bus (BUS)
88 3
P6.2
117 / rw Setpoint input 0 = Fixed frequency (FF0)
1 = Control unit (KEYPAD)
2 = Fieldbus (BUS)
3 = AI1 (analog setpoint 1)
4 = AI2 (analog setpoint 2)
5 = Motor potentiometer
88 3
P6.3
101 - rw Minimum frequency 0.00 - P6.4 Hz 89 0.00
P6.4
102 - rw Maximum frequency P6.3 - 320.00 Hz 89 50.00
60.00
P6.5 103 - rw Acceleration time (acc1) 0.1 - 3000 s 89 3.0
P6.6 104 - rw Deceleration time (dec1) 0.1 - 3000 s 89 3.0
P6.7
505 - rw Start function 0 = Acceleration time (ramp)
1 = Flying restart circuit
90 0
P6.8
506 - rw Stop function 0 = Fee coasting
1 = Deceleration time (ramp)
90 0
P7.1 113 - rw Motor, rated operational
current
0.2 x I
e
-2xI
e
(h Motor rating plate)
94 I
e
P7.3 112 - rw Motor, rated speed 300 - 20000 min
-1
(h Motor rating plate)
94 1440
1720
