04/10 MN04020001Z-EN
List of parameters
177
System parameters in the quick-configuration
P7.4 120 - rw Motor, power factor
(cos v)
0.30 - 1.00
(
h Motor rating plate)
94 0.85
P7.5 110 - rw Motor, rated operating
voltage
180 - 500 V
(
h Motor rating plate)
94 230
400
P7.6
111 - rw Motor, rated frequency 30 - 320 Hz
(h Motor rating plate)
94 50.00
60.00
P11.7 109 - rw Torque increase 0 = Deactivated
1 = Enabled
113 0
M1.1 1 - ro Output frequency Hz 130 0.00
PNU
ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
PNU ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
S1.1 833 - ro API SWD ID - 128 -
S1.2 834 - ro API SW Version - 128 -
S1.3 835 - ro Power SW ID - 128 -
S1.4 836 - ro Power SW Version - 128 -
S1.5 837 - ro Application ID - 128 -
S1.6 838 - ro Application, revision - 128 -
S1.7 838 - ro System load - 128 -
S2.1
1)
808 - ro Communication status RS485 in xx.yyy format
xx = Number of error messages
(0 - 64)
yyy = number of correct messages
(0 - 999)
128
S2.2
1)
809 / rw Error bus protocol 0 = FB disabled
1 = Modbus
128 0
S2.3
1)
810 / rw Slave address 1 - 255 128 1
S2.4
1)
811 / rw Baud rate 0 = 300
1 = 600
2 = 1200
3 = 2400
4 = 4800
5 = 9600
128 5
1) These parameters are overwritten with the bus-specific parameters when a fieldbus connection (e.g. CANopen) is used. The parameter values
described in the manual of the fieldbus interface then apply.
S2.6
813 / rw Parity type 0 = None, no a 2 Stop bits
1 = Even, a 1 Stop bit
2 = Odd a 1 Stop bit
129 0
S2.7
814 / rw Communication timeout 0 = Not used
1 = 1 s
2 = 2 s
…
129 0
S2.8
815 / rw Reset communication
status
0 = Not used
1 = resets parameter S2.1
129 0
