Eaton MMX34AA9D0 Series User Manual

Installation
04/10 MN04020001Z-EN
40
Arrangement and connection of the power terminals
The arrangement and size of the connection terminals depends on
the construction of the power section (FS1, FS2, FS3).
The cross-sections to use in the connections, the tightening
torques for screws and respective fuses are listed in the following.
M3
mm
2
AWG mm inch Nm ft-lbs mm
MMX12AA1D7…
MMX12AA2D4…
MMX12AA2D8…
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS1
MMX32AA1D7…
MMX32AA2D4…
MMX32AA2D8…
MMX34AA1D3…
MMX34AA1D9…
MMX34AA2D4…
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS1
MMX11AA1D7...
MMX11AA2D4...
MMX11AA2D8...
MMX11AA3D7...
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS2
MMX12AA3D7…
MMX12AA4D8…
MMX12AA7D0…
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS2
MMX32AA3D7…
MMX32AA4D8…
MMX32AA7D0…
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS2
MMX34AA3D3…
MMX34AA4D3…
MMX34AA5D6…
0.2 - 2.5 24 - 12 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS2
MMX11AA4D8... 0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS3
MMX12AA9D6… 0.2 - 4 24 - 10 8 0.31 0.5 - 0.6 0.37 -
0.44
0.6 x 3.5 FS3
L1
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3
L3
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3
L1
L2/N
e e
U/T1
V/T2
W/T3
L3 R+ R-
L3
L2/N
U/T1
V/T2
W/T3
e e
L1
L2/N
e e
U/T1
V/T2
W/T3
