Eaton MMX34AA9D0 Series User Manual

04/10 MN04020001Z-EN
List of parameters
179
All Parameters
h
When first switching on or after activating the default
settings (S4.2 = 1) parameter P1.1 must be set to 0 for
access to all parameters.
PNU ID Access right Designation Value range Page FS
(P1.3)
User
setting
RUN ro/rw
Parameter selection
P1.1
115 / rw Parameter conceal 0 = All parameters
1 = Only quick configuration parameters
73 1
P1.2
540 - rw Drive Setup 0 = Basic
1 = Pump drive
2 = Fan drive
3 = Hoisting device (high load)
73 0
P1.3
1472 - rw Country specific default
settings (FS)
0 = EU
1 = USA
73 0
Analog input
P2.1 379 / rw AI1, Signal range (microswitches S2)
0 = 0 - +10 V/0 - 20 mA
1 = 2 - +10 V/4 - 20 mA
75 0
P2.2
380 / rw AI1 Custom Min -100.00 - 100.00 % 75 0
P2.3
381 / rw AI1 Custom Max -100.00 - 100.00 % 75 100
P2.4
378 / rw AI1 Filter time 0.0 - 10.0 s 75 0.1
P2.5
390 / rw AI2, Signal range (microswitches S3)
Like P2.1
76 1
P2.6
391 / rw AI2 Custom Min -100.00 - 100.00 % 76 0
P2.7
392 / rw AI2 Custom Max -100.00 - 100.00 % 76 100
P2.8
389 / rw AI2 Filter time 0.0 - 10.0 s 76 0.1
Digital input
P3.1
300 / rw Start/Stop Logic 0 = DI1 (FWD), DI2 (REV), REAF
1 = DI1 (FWD) + DI2 = REV
2 = DI1 (Start pulse), DI2 (Stop pulse)
3 = DI1 (FWD), DI2 (REV)
79 3
P3.2 403 / rw Start signal 1 (FWD) 0 = Deactivated
1 = Activated via control signal
terminal 8 (DI1)
2 = Activated via control signal
terminal 9 (DI2)
3 = Activated via control signal
terminal 10 (DI3)
4 = Activated via control signal
terminal 14 (DI4)
5 = Activated via control signal
terminal 15 (DI5)
6 = Activated via control signal
terminal 16 (DI6)
79 1
P3.3
404 / rw Start signal 2 (REV) like P3.2 79 2
P3.4
412 / rw Reverse like P3.2 79 0
P3.5
405 / rw Ext. fault close like P3.2 79 0
P3.6
406 / rw Ext. fault open like P3.2 79 0
