Cables and fuses
157
Cables and fuses
The cross-sections of the cables and line protection fuses used
must correspond with local standards.
For an installation in accordance with UL guidelines, the fuses and
copper cable that are UL-approved and have a heat-resistance of
+60/75 °C are to be used.
Use power cables with insulation according to the specified mains
voltages for the permanent installation. A shielded cable is not
required on the mains side. On the motor side however, a
complete (360°), low-impedance, shielded cable is necessary.
The length of the motor cable depends on the radio interference
class and is a maximum of 30 m at M-Max
TM
.
Table 11: Fuses and Maximum Cross-Sections
F1, Q1 = L1, L2/N, L3 U, V, W R+, R- PE
1~ 3~ mm
2
AWG
1)
mm
2
AWG
1)
mm
2
AWG
1)
mm
2
AWG
1)
MMX11AA1D7N0-0
MMX11AA2D4N0-0
MMX11AA2D8N0-0
MMX11AA3D7N0-0
20 A - 2 x 2.5 2 x 14 3 x 2.5 3 x 14 - - 2.5 14
MMX12AA1D7…
MMX12AA2D4…
MMX12AA2D8…
MMX12AA3D7…
10 A - 2 x 1.5 2 x 16 3 x 1.5 3 x 16 - - 1.5 16
MMX32AA1D7N0-0
MMX32AA2D4N0-0
MMX32AA2D8N0-0
MMX32AA3D7N0-0
MMX34AA1D3N0-0
MMX34AA1D9N0-0
MMX34AA2D4N0-0
- 6A 3 x 1.5 3 x 16 3 x 1.5 3 x 16 - - 1.5 16
MMX34AA3D3…
- 6A 3 x 1.5 3 x 16 3 x 1.5 3 x 16 2 x 1.5 2 x 16 1.5 16
MMX11AA4D8… 32 A
2)
- 2 x 6 2 x 10 3 x 6 3 x 10 - - - -
MMX12AA4D8…
MMX12AA7D0…
20 A - 2 x 2.5 2 x 14 3 x 2.5 3 x 14 - - 2.5 14
MMX32AA4D8…
MMX32AA7D0…
- 10 A 3 x 1.5 3 x 16 3 x 1.5 3 x 16 - - 1.5 16
MMX34AA4D3…
MMX34AA5D6…
3 x 1.5 3 x 16 3 x 1.5 3 x 16 2 x 1.5 2 x 16 1.5 16
MMX12AA9D6… 32 A
1)
- 2 x 6 2 x 10 3 x 6 3 x 10 - - 6 10
MMX32AA011…
MMX34AA7D6…
MMX34AA9D0…
MMX34AA012…
- 20 A 3 x 2.5 3 x 14 3 x 2.5 3 x 14 2 x 2.5 2 x 14 2.5 14
MMX34AA014…
- 25 A 3 x 4 3 x 12 3 x 4 3 x 12 3 x 4 2 x 12 4 12
1) AWG = American Wire Gauge
2) 30 A with AWG
