M-Max
TM
Series
04/10 MN04020001Z-EN
14
General rated operational data
Technical data Symbols
used in
technical
data and
formulae
Unit Value
General
Standards EMC: IEC/EN 61800-3,
Safety: IEC/EN61800-5, UL508C
Certifications and manufacturer's declarations on
conformity
EMC: CE, CB, c-Tick
Safety: CE, CB, UL, cUL
Production quality RoHS, ISO 9001
Climatic proofing p
w
% < 95 %, average relative humidity, non-condensing (EN50178)
Air quality
Chemical vapors IEC721-3-3: Device in operation, Class 3C2
Mechanical particles IEC721-3-3: Device in operation, Class 3S2
Ambient temperature
Operation i °C -10 - +40 (+50
1)
)
Storage i °C -40 - +70
Installation altitude H m 0 – 1000 m above sea level, over 1000 m with 1% power reduction per
100 m, maximum 2000 m, at maximum +50 °C ambient temperature
Mounting position Vertical ±90
Protection type IP20
Busbar tag shroud BGV A3 (VBG4, finger and back-of-hand safe)
Overvoltage category/pollution degree -
Mechanical shock resistance IEC 68-2-27
Storage and transport: 15 g, 11 ms (in the packaging)
UPS drop test (for applicable UPS weights)
Vibration EN 60068-2-6
3 – 150 Hz, oscillation amplitude 1 mm (Peak) at 3 – 15.8 Hz,
maximum acceleration amplitude 1 g at 15.8 – 150 Hz
Emitted interference with internal EMC filter
(maximum motor cable length)
C2: Class A in 1st environment (residential area with commercial
utilization)
C3: Class A in 2nd environment (Industrial)
MMX11, MMX12
C2, C3
MMX32, MMX34 C2, C3
Power section
Rated operational voltage f
LN
Hz at 50/60
MMX11 U
e
VAC 1~115(110-15%-120 +10%)
MMX12 U
e
VAC 1~230(208-15%-240 +10%)
MMX32 U
e
VAC 3~230(208-15%-240 +10%)
MMX34 U
e
VAC 3~400(380-15% - 480 +10%)
Mains network configuration (AC power supply
network)
Center-point grounded star network (TN-S network)
Phase grounded AC networks are not permitted.
Mains switch-on frequency Maximum one time per minute
Mains current THD %
> 120
Short-circuit current I
K
kA maximum < 50
