04/10 MN04020001Z-EN
Rating data on the nameplate
13
Examples
Example: MMX34AA5D6N0-0.
Assigned interference suppression filter: MMX-LZ3-009
(three-phase interference suppression filter up to 9 A, size FS2)
Label Meaning
MMX11AA2D8N0-0 MMX = frequency inverter of the M-Max
TM
series:
1 = Single-phase power supply
1 = Rated voltage 115 V
AA = Type of software version and display
unit
2D8 = 2.8 A (rated operational current)
N = No integrated interference suppression
filter (No filter)
0 = IP20 protection type
0 = No integrated optional assembly
MMX12AA1D7F0-0
MMX = frequency inverter of the M-Max
TM
series:
1 = Single-phase power supply
2 = Rated voltage 230 V
AA = Type of software version and display
unit
1D7 = 1.7 A (rated operational current)
F = Integrated radio noise filter
0 = IP20 protection type
-0 = No integrated optional assembly
MMX32AA2D4N0-0
MMX = frequency inverter of the M-Max
TM
series:
3 = Three-phase mains supply voltage
2 = Rated voltage 230 V
AA = Type of software version and display
unit
2D4 = 2.4 A (rated operational current)
N = No integrated interference suppression
filter (No filter)
0 = IP20 protection type
-0 = No integrated optional assembly
MMX34AA012F0-0
MMX = frequency inverter of the M-Max
TM
series:
3 = Three-phase mains supply voltage
4 = Rated voltage 400 V
AA = Type of software version and display
unit
012 = 12 A (rated operational current)
F = Integrated radio noise filter
0 = IP20 protection type
-0 = No integrated optional assembly
MMX34AA5D6N0-0
MMX = frequency inverter of the M-Max
TM
series:
3 = Three-phase mains supply voltage
4 = Rated voltage 400 V
AA = Type of software version and display
unit
5D6 = 5.6 A (rated operational current)
N = No integrated interference suppression
filter (No filter)
0 = IP20 protection type
-0 = No integrated optional assembly
h
MMX11: The mains voltage of 115 V is raised to 230 V
(output voltage) through an internal voltage double
connection.
h
MMX… N…: An externally fitted interference suppres-
sion filter is required for operation in accordance with IEC/
EN 61800-3.
